Katon KT-KD50X ATEM Vmix Control Panel
Katon KT-KD50X ATEM Vmix Control Panel Professional Live Production Controller & Video Switcher Console with integrated hardware design, multi-channel switching, ATEM / vMix / OBS compatibility, 12-channel live switching, audio control, T-BAR fader, and 24-channel tally output. Built for live production, broadcasting, streaming, and event directing.
₹48,000
Professional Live Production Controller for Seamless Video Switching
Take full control of your live productions with this all-in-one Broadcast Production Controller, designed for professional directors, live streamers, and production teams. Featuring integrated video switching, audio adjustment, transition control, and tally output, this compact hardware controller simplifies complex live production workflows while delivering fast and reliable performance.
Key Features
| Main Parameters | |
|---|---|
| Audio Control | 1ch master+4ch input |
| Transition Control | Auto transitions, hard cuts, T-Bar |
| OLED Display | Set device parameters |
| Indicator Light | Indicate switcher status |
| Tally | 12ch PGM+12ch PVW |
| ATEM Functions: | |
| Connection Method | 100M LAN，support POE 802.3af |
| Video Control | 12ch inputs |
| Transition Effects | MIX / DIP / WIPE / STING / DVE |
| Upstream Keyboard | BKGD / KEY1 / KEY2 / KEY3 / KEY4 |
| Downstream Keyboard | DSK1 / DSK2 |
| FTB | Support |
| PREV TRANS | Support |
| MACRO | Support |
| S/SRC | Support |
| M/E | Support |
| AUX | Support |
| vMix Functions: | |
| Connection Method | 100M LAN，support POE 802.3af；USB |
| Video Control | 12ch inputs |
| Transition Effects | 4 kinds |
| Picture-in-picture Function | R1 / R2 / R3 / R4 |
| Playback Setting | M1 / M2 |
| REC | Support |
| LIVE | Support |
| T-BAR | Support |
| Power Supply | |
| Input Voltage | DC 12V |
| Input Current | 0.3A |
| Rated Power | 4W |
| POE | POE 802.3af for optional |
| Powered by USB | Support ( rely on the USB power supply capability of the computer) |
| General Specifications | |
| Use Environment | Indoor |
| Operating Temperature | -10℃~40℃ |
| Storage Temperature | -20℃-60℃ |
| Dimension | (W)354*(D)165*(H)67mm |
| Weight | 1.5kg |
| Accessories | Power adapter*1, USB cable*1, User manual*1 |
| Weight | 1.5 kg |
|---|---|
| Dimensions | 35.4 × 16.5 × 6.7 cm |
